Información Básica.
No. de Modelo.
LC1-D
certificado
ce/cb/ccc
vida útil mecánica
20000000
material
contacto de cobre
calidad
r
color
naranja blanco
experiencia
13years
precio
competitivo
garantía
3years
frenquncy
50/60hz
oem
sí
Paquete de Transporte
Cartons
Marca Comercial
KAYAL
Origen
China
Capacidad de Producción
100000pieces/Month
Descripción de Producto



AplicacióN
LC1-D contactor AC es adecuado para utilizar en los circuitos hasta la tensióN nominal de 660V,AC 50Hz o 60Hz, la corriente nominal de hasta 95A,para hacer ,rompiendo frecuentemente &A partir de la máQuina-dispositivo de enclavamiento etc, se convierte en el contactor dalay,contactor de enclavamiento mecáNico, Arrancador estrella-triáNgulo.Con el reléTéRmico,se combinan en el motor de arranque electromagnéTico.El contactor es producida segúN IEC947-2,VDE0660&BS5442
La especificacióN
Tipo | LC1-D09 | LC1-D12 | LC1-D18 | LC1-D25 | LC1-D32 | LC1-D40 | LC1-D50 | LC1-D65 | LC1-D80 | LC1-D95 | |
Workingcurrent nominal (A) | AC3 | 9 | 12 | 18 | 25 | 32 | 40 | 50 | 65 | 80 | 95 |
AC4 | 3.5 | 5 | 7.7 | 8.5 | 12 | 18.5 | 24 | 28 | 37 | 44 | |
Standardpower Ratingsof Motores de 3 fases Incategory 50/60 Hz AC-3 | 220/230 V | 2.2 | 3 | 4 | 5.5 | 7.5 | 11 | 15 | 18.5 | 22 | 25 |
380/400V | 4 | 5.5 | 7.5 | 11 | 15 | 18.5 | 22 | 30 | 37 | 45 | |
415V | 4 | 5.5 | 9 | 11 | 15 | 22 | 25 | 37 | 45 | 45 | |
500V | 5.5 | 7.5 | 10 | 15 | 18.5 | 22 | 30 | 37 | 55 | 55 | |
660/690V | 5.5 | 7.5 | 10 | 15 | 18.5 | 30 | 33 | 37 | 45 | 55 | |
El calor nominal de Corriente (A) | 20 | 20 | 32 | 40 | 50 | 60 | 80 | 80 | 125 | 125 | |
Vida eléCtrica | AC3 (x104) | 100 | 100 | 100 | 100 | 80 | 80 | 60 | 60 | 60 | 60 |
AC4 (x104) | 20 | 20 | 20 | 20 | 20 | 15 | 15 | 15 | 10 | 10 | |
Vida mecáNica (x104) | 1000 | 1000 | 1000 | 1000 | 800 | 800 | 800 | 800 | 600 | 600 | |
NúMero De Contactos | 3P+N | 3P+NC+N | |||||||||
3P+NC |
El voltaje del circuito de control estáNdar
V. | 24 | 42 | 48 | 110 | 220 | 230 | 240 | 380 | 400 | 415 | 440 | 500 | 600 |
50Hz | B5 | D5 | E5 | F5 | M5 | P5 | U5 | Q5 | V5. | N5 | R5 | S5 | Y5 |
60 Hz. | B6 | D6 | E6 | F6 | M6 | - | U6 | Q6 | - | - | R6 | - | - |
50/60 Hz | B7 | D7 | E7 | F7 | M7 | P7 | U7 | Q7 | V7 | N7 | R7 | - | - |
